PlantCtrl/website/content/Hardware/_index.md

title, date, draft, description, tags

title	date	draft	description	tags
Hardware	2025-01-24	false	The Hardware	esp32 hardware

{{< gallery >}} {{< /gallery >}}

{{< gitea server="https://git.mannheim.ccc.de/" repo="C3MA/PlantCtrl" >}}

ESP32-C6

• RiscV
• Fully done in Kicad (#schematics here link)
• Supports 16 Moisture Sensors (two per plant)
• Support for 8 Pumps/Valves
• Support for main Pump/Valve
• All Pump/Valve outputs are 7-24V based on supplied Voltage
• Use of efficient DC-DC Converters for 3.3V and for Led-Nightlight
• Embedded Solar MPPT Charger
• Can also be used with a power supply

Made with:
