## Modular Design
The PlantCtrl hardware has been redesigned from a single large PCB into a more flexible, modular system. This allows users to only build or use the components they actually need for their specific setup.

The system now consists of a **MainBoard** which acts as the controller and several pluggable or connectable modules.

## MainBoard (ESP32-C6)
* **Processor:** ESP32-C6 (RiscV)
* **Connectivity:** WiFi, Bluetooth, Zigbee/Thread support
* **Form Factor:** Compact main board with headers for modules
* **Fully Open Source:** Designed in KiCad

## Available Modules
* **MPPT Charger:** Efficient solar charging for batteries.
* **Pump Driver:** High-current outputs for pumps and valves.
* **Sensor Interface:** Support for multiple moisture sensors.
* **Light Controller:** For LED nightlights or growth lights.

## Capabilities
* **Moisture Sensors:** Supports multiple capacitive or resistive sensors via expansion modules.
* **Pumps/Valves:** Support for multiple independent watering zones.
* **Power:**
    * Solar powered with MPPT
    * Battery powered with optional Battery Management (Fuel Gauge)
    * Can also be used with a standard power supply (7-24V)
* **Efficient Power:** Use of high-efficiency DC-DC converters for 3.3V and peripherals.
